Description

• HDMI 2.0b, HDCP 2.2 / HDCP 1.4 compliant.
• Supports HDMI resolution the maximum up to 4K2K @ 50/60Hz (4:4:4).
• Supports digital and analogue audio extract output from HDMI source.
• Supports output bypass and 4K -> 1080P down-scaler function via dial switch on panel.
• EDID can be selected COPY and AUTO modes via dial switch on panel. (COPY: It copies OUT 1 port EDID setting to all outputs port, If no HDMI OUT 1 capable EDID is detected then the unit will copy HDMI OUT 2. If no HDMI 1~2 capable EDID is detected then the unit will copy HDMI OUT 3… etc. The priority order is OUT 1 to OUT 4. AUTO: Compare OUT 1 ~ OUT 4 EDID setting and output the best resolution to all outputs).
• Supports analogue audio PCM 2.0.
• Supports optical audio pass-through format about LPCM 2.0 / 2.1 / 5.1 CH, Dolby 5.1, Dolby True HD, Dolby DD+, DTS 5.1, DTS-ES 6 / DTS-HDMA 5.1, DTS HD-HRA 5.1.

Packing List:

• 1 x 1×4 HDMI 2.0 Splitter
• 1 x 5V / 1A Power Adapter
• 1 x User Manual
