Description

• HDMI 1.4 and HDCP 1.4 compliant.
• Video Resolution up to 4K2K @ 30Hz (4:4:4) 8-bit.
• Support audio formats: LPCM 7.1 CH, Dolby True HD, and DTS-HD Master Audio.
• Extend the signal transmission distance up to 131ft / 40 meters at the resolution of 4K30Hz, or 230ft / 70 meters at 1080P@60Hz via a single CAT6 cable.
• Support 1 HDMI input, 1 HDMI loop output and 8 CAT outputs.
• Advanced EDID management.
• Support 12V POC function (only from transmitter to receiver).
• Compact design for easy and flexible installation.

Packing List:

• 1 x HDMI 1×8 Splitter
• 1 x IR Blaster Cable (1.5m)
• 1 x 12V / 2.5A DC Locking Power Adapter
• 1 x User Manual
• 2 x Mounting Ear
• 8 x CAT Receiver
• 8 x IR Receiver Cable (1.5m)
• 8 x Machine Screw (KM 3×4)
