Description

• HDMI 2.0b, HDCP 2.2 and HDCP 1.4 compliant.
• Video resolution up to 4K2K @ 60Hz (YUV 4:4:4) on all HDMI ports.
• Supports 18 Gbps video bandwidth.
• Dolby Vision, HDR 10+ and HLG are supported.
• Support 4K -> 1080P Down Scaler for each output port.
• HDMI audio pass-through up to 7.1 CH HD audio (LPCM, Dolby TrueHD and DTS-HD Master Audio).
• Audio de-embedded is supported via analogue and coax ports.
• ARC, CEC and smart EDID management are supported.
• 1U rack mounted design with front panel OLED display.
• Control via front panel buttons, IR remote, RS232, LAN and Web GUI.

Packing List:

• 1 x 18 Gbps 8×8 HDMI Matrix
• 1 x 12V / 5A Power Adapter
• 1 x IR Remote
• 1 x IR Receiver Cable (1.5m)
• 1 x RS232 Serial Cable (Male to Female Head, 1.5m)
• 1 x User Manual
• 2 x Mounting Ear
