| Ethernet Input | 1000 m bit/s |
| Ethernet Protocols | TS Protocol, RTSP / HTTP TS / HTTP FLV / RTMP / UDP, Private HTTP PTE |
| Video Decoding | H.265 Main Profile
H.264 Baseline / Main / High Profile L4.2 |
| Bit Rate (Kbps) | 32 – 32000 |
| Resolution | Max 3840 x 2160 @ 30 fps / 1080P @ 60 fps |
| Video Decoding Channel | Max 4 Channels |
| Audio Decoding Types | G711A / G711U / AAC / AAC+ / AAC++ / AC3 / MP2 / MP3 |
| Audio Channel | Left and Right Stereo |
| Sampling Rate | 8000 / 11250 / 22500 / 44100 / 48000 Hz |
| VGA Output | 1080P @ 60 / 1080I @ 60 / 1080P @ 50 / 1080I @ 50 / 1080P 30 / 1080P 25 / 720P 60 / 720P 50 / 576P 50 / 480P 60 |
| HDMI Output | 2160P @ 30 / 1440P @ 30 / 1080P @ 60 / 1080I @ 60 / 1080P @ 50 / 1080I @ 50 / 1080P 30 / 1080P 25 / 720P 60 / 720P 50 / 576P 50 / 480P 60 |
| CVBS | PAL 720 x 576 / NTSC 720 x 480 |
| Dimensions – mm
(L x H x D) |
134.2 x 104.5 x 24 |
| Net Weight | 410g |
| Operating Temperature | 32℉ to 104℉ (0℃ to 40℃) |
| Storage Temperature | 14℉ to 140℉
(- 10℃ to 60℃) |
| Power Consumption | 3W (Max) |
