Description

• Extension of USB 3.0 up to 100m / 328ft over CAT6a cable.
• USB 3.0 connectivity with data transfer rate up to 5 Gbps.
• Backwards compatible with USB 2.0 and 1.1.
• Hardware acceleration for isochronous and bulk transfer.
• USB-A port 1 and 2 support 5V / 1.5A, port 3 and 4 support 5V / 1A on the Receiver.
• Support RS-232 pass-through and FSYNC GPIO pass-through (For industry camera use).
• Support bi-directional 24V PoC.
• Simple plug and play, no driver and setting installation required.

Packing List:

• 1 x USB 3.0 Extender (Transmitter)
• 1 x USB 3.0 Extender (Receiver)
• 1 x 24V 2A locking power supply
• 1 x User Manual
• 2 x 4-pin 3.5mm phoenix connector (Male)
• 4 x Mounting ear
• 8 x Machine screw KM 3×4
